R40 UHF 4ch Receiver “Modular Voice PRO Line”

The UHF Modular system created by Empire allows you to configure the microphone system according to your needs!

The UHF Rack Receiver with 4 channels, TY.R40, ensures reliable and high-quality reception and transmission. It has been designed to interface seamlessly with microphones from the Modular Voice PRO Line. The configuration system is extremely simple; just bring the microphone close to the receiver, and thanks to the infrared system, synchronization occurs automatically: it’s foolproof for anyone who has never dealt with this type of system.

The available channels to choose from are 200, allowing the installation of multiple receivers for larger setups. Volume adjustment is separate for each channel. Each channel is equipped with a balanced XLR output. There is also a 6.3mm Jack output that mixes the four channels, very useful for a simpler connection directly to an audio system with a separate microphone input, such as the Empire WB-180PRO.

  • Power Supply: DC12V/1A
  • Working Current: 310 mA
  • Working Power: 3.72W
  • Channel: 200 Channels
  • Carrier Band: UHF 640-699.7MHz
  • Modulation Mode: PLL Phase-Locked Loop Integrated Control
  • Noise Suppression: >70dB
  • Radio Frequency Stability: ±0.005% (10-50°C)
  • Maximum Offset: ±35KHz
  • Bandwidth: 60MHz
  • Frequency Interval: 300KHz
  • Integrated Frequency Response: 40Hz~19.5KHz ±3dB
  • Output Socket: 4 X Balanced / 1 X Mix
  • Frequency Adjustment: IR Infrared Automation
  • Scope of Use: >80m
  • Receiving Sensitivity: -85 about 2dB
  • Weight: 1.85 (Kg)
